Power supply: AC 110-240V/50Hz~60Hz Power consumption: 1200W Light source : 1000W LED module Electrical strength: 1.5KV Insulation resistance: > 2m Ω Working temperature:-30 ℃ ~ 45 ℃ Color temperature: 8000K Luminous flux: 69000 lm Ra:71 (optional high display finger) Safety grade of electrical appliances: class I Color plate: 7 colors + white light (customizable) Color function: forward rotation, inversion, rainbow water, adjustable speed Picture disk: 2 6 x 1 rotating pattern plates with rotation Pattern rotation: forward rotation, inversion, pattern fixed point, adjustable speed Focusing: linear focusing Optical angle: 6 °- 60 °(linear zoom) Control protocols: DMX512, RDM Data connection: 3p-XLR/ input / output IP67 waterproof power supply and signal connector, anti-UV core material Channels: 18CH Control mode: DMX512/ manual mode control / Auto mode / offline mode Automatic mode: single machine self-programming does not need console, according to the need to edit the effect program on the lamp display board, save after independent memory, master / slave online synchronous operation. LCD screen, display lamp information in all Chinese, easy to control and view all kinds of lighting information Fixture Protection: full Lamp structural Waterproof IP65 Built-in temperature control function, when the light source is overheated, the output power of the light source can be reduced intelligently; multiple light projections can be spliced Installation mode: vertical hanging, inverted hanging Heat dissipation mode: heat pipe radiator + fan heat dissipation Shell material: die casting aluminum and profile aluminum Fixture body color: dark gray coating, customizable other colors Working temperature:-30 ℃ ~ 45 ℃ Protection rate: IP65 Dimension size: 571 × 466 × 489mm
