HSA052 LED FLOWER PATTERN
HSA052 is large LED gobo Light. The white light focus by convex lens first, and through the gobo wheel and color wheel which are not controlled by motor, finally form many kinds of colorful gobo effects via convex lens’ focusing. There are 10 DIP switch on the back side of the light, a network cable socket
with one input and one output, and a 12V DC input socket.  It’s easy to control and operate, with small and exquisite appearance, stylish and practical, excellent beam effects. Widely used at home, KTV room, Disco Hall and other small entertainment places.
Light Source: 8W LumiEngin-SC3
LED Lamp Life:50000 hours
DIP Switch:10
Control Channel:4 DMX Channels
Control Protocol: International standard DMX512 control protocol
Strobe:High- speed electronic adjustment strobe,  1- 20 flashes / sec
Control Mode:DMX , Sound Activate , AUTO
Optical effects: t The white light focus by convex lens first, and through the gobo
wheel and color wheel which are not controlled by motor, finally form many kinds of
colorful gobo effects via convex lens’ focusing.
Protection Rating:IP20
Input Power:Adapter AC100-240V  Light DC12V
DMX Socket:RJ45 network socket with one input and one output.
Power consumption:13.5W
Working Environment:up to 40℃
Lighting maximum surface temperature:50℃
Dimension:140.8×¢102mm
Gift box Package:250X150X115 (1pc/CTN)
Master Package:505X460X365(18pcs/CTN)
N.W:0.64Kg (1PC)
G.W:0.98 kg (1PC)
Application Fields: Widely used at Home, KTV room, Disco Hall, and small entertainment places, etc.
