SPC069A is onekind of powerful 8W LED moving head beam light，it uses brand new and beautiful metal and plastic bodywith excellent performance of resistance to high heat and hard force. With CE& CCC certificates and according to the standard of USITT DMX512, the lightis available to stand alone control and also master/slave mode, and it featuresquiet and fast operation with multi functions. Their application could bestage, studio, club and bars etc.

Ⅰ. Light source characteristic

Light source:4×8WLED white

Life span: 10000hours

High qualityoptical lens

LED typel:1770LUX@7M

High efficiencyand low noise cooling system

Beam angle 11°

white light 6500K

Ⅱ. Electrical parameters

Multi voltageelectronic power supply

Power supply:

AC 100-240V,50/60Hz

Ⅲ. Mechanical parameters

Length:107 mm(4.2" )

Width: 999 mm (39.3")

Height: 266 mm (10.5")

N.W: 11.2 kg

G.W: 13.5 kg

Packing:1175×310×180 mm

Ⅳ. Lighting control

LCD display

DMX channels:6/18channels USITT DMX 512

Flash: Electronicstrobe and dimming; 1-18 pulses one second

Dimmer: Electroniclinear dimming 0-100%

Scanner: Pan540°Tilt 270°with automatic error correction

with 8-bit and16-bit rotation accuracy, precise positioning, rotation speed adjustable errorcorrection

4 mini moving headlights, individually controllable, efficient LED light off, speed controllable.

The lighting istwo power terminals, one is input, another is output

Controls:DMX,Master/Slave,Soundactivate, Auto
