GA080B is economicstage Moving Head Beam with high brightness. Efficient and accurate three-phasemotor drive creating a pan and tilt high-speed operation.

Eight prismscombined with gobos and color wheel can create unlimited dynamic pattern effect.

Suitable for:Theater, Studio, Arts performing, Auditorium, Lecture hall, Gymnasium and theother Large and medium-sized performing places.

Ⅰ.Light Source

Lamp type：OSRAM 230W

Typical lumen maintenancerate：70% @ 2000 hours

Ⅱ.Optical Effects

Beam angle: 4°

Color: one colorwheel with 14 colors+ white

Gobo wheel： 17 plug gobos + white

The rotating eightprisms can be any direction of rotation, with precise positioning function.

High-brightness lamp,luminous flux for 7950 lm, color temperature of 8000K.

0 ~ 100% linearautomization effect

0 ~ 100% lineardimming function

With random strobefunction.

 Ⅲ.Electricalparameters

Power supply：AC 100-240 V,50/60Hz

Power consumption：350 W

IV.Mechanicalparameters

Length：353 mm ( 13.9" )

Width：283 mm ( 11.1")

Height：491 mm ( 19.3")

Packing size：480 x 440 x 610 mm

N.W：15.7 kg

G.W：18.6 kg

V.Temperaturecharacteristics

WorkingEnvironment：up to 40℃

VI.Light Control

Display: LCDdisplay

Channel: 16 DMXchannels

Flash：Double Straw Chopper flashes the highest frequency of14 times / sec, random flash and pulsed flash optional.

Dimmer：0~100% linear dimming function

Rotation：Pan 450° Tilt 270°

With 8-bit and16-bit rotation accuracy, precise positioning, rotation speed adjustable

VII.Safety andappearance

Housing:Fiber-reinforced composites, anti-ultraviolet (UV)

Protection rate：IP20
