SPB301 uses a 15wRGB 3 in 1 LED light source, it has is very eco-friendly power consumption. Theoptical system produces a very smooth, high quality light output ofrich,beautiful colours with no shadows .

It is ideal forall small-to-medium applications,particularly those where space andaccessibility is an issue.

Ⅰ. Light Source

Lamp type：1×15W LED ( RGB 3 in 1)

Typical lumenmaintenance rate: 70%@50000 hours

Ⅱ. Optical Effects

Optical lens withhigh luminous effect

Electronic flashwith adjustable speed

Unlimited mixingcolor with RGB

Ⅲ. Electrical Specification

Power supply:AC100-240V,50/60Hz

Power consumption：50W

Ⅳ.Mechanical Specification

Length：177 mm ( 7" )

Width：177 mm ( 7")

Height：250 mm ( 9.8")

Packing size：378 x 236 x 262 mm

N.W：3.1 kg

G.W：3.8 kg

Ⅴ. Temperature Specification

WorkingEnvironment：up to 40℃

Over- heatedprotection

Ⅵ. Light Control

Display: LEDdisplay

Channels:8/13 DMXchannels

Electronicadjustable flash with high speed

Rotation:Ultramicroand smooth scanning in wild scope,pan 540°Tilt 270° with automatic errorcorrection

With 8-bit and16-bit rotation accuracy, precise positioning, rotation speed adjustable,adjustable speed of rotation

Controls: Soundactivate, Master/Slave, Auto, DMX

Ⅶ. Safetyand appearance

Housing:high-temperatureresistance plastics

Perfect appearancedesign

Protection rate：IP20

• SPB301.R20
