SPB012 is a washlight with 19 high quality LED light source and zoom function, high speed motorwhich makes it move fast and smoothly.

This light has 3LED zones with individual control of each that produces infinite color effects.Electronic zooming and precise adjustment on beam angle which makes the lightto be ideal choice for beam washing. Equipped with diverse strobe modes, theluminaire is powerful to make an impressive lighting effect.

SPB012 is easy tooperate, built-in programming is to make different colors and strobe effects.

Ⅰ.Light Source

Light type: LED19×10W RGBW

Typical lumenmaintenance rate: 70% @ 60000 hours

Ⅱ. Optical Effects

High qualityoptical lens

Infiniteadjustable beam angle; beam angle range 9°- 37°

CTO filter

White color isadjustable on temperature color (3200K/5600K/8000K)

Infinite RGBWcolor mixing; with RGB color wheel function

Color running withrainbow effect

3 LED zones withindividual control of each; RGBW zone with macro function

Zone effects withvariable speed

Precise dimming0~100%

Strobe effect withvariable speed

Electronic zooming

Built-in randomstrobe programming

Ⅲ. Electronic Specification

Power supply: AC 100-240V,50-60Hz.

Power consumption:230W

Ⅳ.Mechanical Specification

Length: 270 mm(10.6”)

Width: 203 mm (8”)

Height: 365 mm(14.4”)

Packing size:320×320×480 mm

           660×660×504 mm (4PCS/CTN)

N.W : 5 kg

G.W : 6 kg

Ⅴ.Temperature specification

WorkingEnvironment: up to 40℃

over-heat protectfunction

Ⅵ. Light Control

Display: LCDdisplay

Channels: 18 DMXchannels

Strobe: mechanicstrobe effect with high frequency 1~18 times/second

Dimmer: electronicdimming (0 ~ 100%)

Rotation: Pan 450°,tilt 270 °and auto error correction；8 bits and 16 bits precision control
