Powersupply：AC 100–240V，50/60Hz

Power consumption：470W

Light source：OSRAM HRI280W OR YODN
Life Time：2200 hours
Color temperature：8000K
Beam angle：2.5-20°
Control panel：LCDtouch screen display function

controls： auto，master/slave，DMX512，Automatic
DMX channels：16/24channels mode
Pan/Tilt rotation：540°/270°,speed adjustable
Color ：13color+white，withforward and reverse rainbow effect.
Gobo wheel：gobo Iwith auto rotation of each gobo (9 gobos plus white color);
                   gobo II(14 gobos plus white color)
Prism 1：8-facetcircular prism rotating in both directions at different speeds

Prism 2：6-facet linear prism rotating in bothdirections at different speeds

Focus ：Linear adjustment

Dimmer：0-100% linear dimming function
Strobe：Flashspeed up to 10 times / sec, random flash optional

Wash effect：Adjustable Wash effects angle

Workingenvironment：up to 40°C
Protection rate：IP20
Cover：A3,Plastic
Dimensionsize：386×365×530mm
Packing size：445×430×570mm
N.W：19 kg
G.W：21 kg

• GA086K-16CH.r20
• GA086K-24CH.r20
